Product Details:
|
| Color: | Orange Or Customed | Application: | Outdoor Or Emergency |
|---|---|---|---|
| Input DC: | DC 12~24V;5A | Output AC: | 220V |
| High Light: | 110V portable lithium generator,lithium ion portable power station,1200W lithium ion portable power station |
||
AC - 220V / 110V Output 1200W Lithium-ion Portable Power Station Power Supply for Power Grid Outage
Specifications
|
Model # |
BDX-600 |
BDX- 1000 |
BDX- 1200 |
|
Battery Capacity |
12V 45Ah(531WH) |
12V 80AH( 1013WH) |
12V90AH( 1153WH) |
|
Output Power |
600W |
1000W |
1200W |
|
Input voltage |
AC 110V~220V 50/60Hz, solar or wind energy DC 13-30V input, vehicle 12V input, no controller. |
||
|
Output voltage |
220V 50Hz / 110V 60Hz |
||
|
DC output |
12V/4A *3; USB5V/2. 1A *2; QC3.0 *1; TYPE-C *; (PD3.0 fast charging 5V/3A,9V/2A, 12V/ 1.5A) |
||
|
Communication |
Computer data monitoring universal USB 1 (mobile phone Internet monitoring function, optional) |
||
|
LED lights |
1W |
||
|
Solar charging |
18V60W/ 120W (optional) |
||
|
Output waveform |
pure sine wave |
||
|
Power outage response time |
≤5 ms |
||
|
Overload |
After overloading, the AC output is disconnected, the indicator light is red, the load is disconnected. Please restart to continue using |
||
|
Short circuit |
After the short circuit, the AC output is disconnected, the load is disconnected, Please restart to continue using |
||
|
Lithium battery |
Cycle life more than 600 times |
||
|
Net weight |
5.95kg |
8.8kg |
9.8kg |
|
Gross weight |
7.2kg |
10.2kg |
11.2kg |
|
Product Size |
266*160*168mm |
380*160*168mm |
415*160*168mm |
|
Package dimensions |
380*230*225mm |
468*230*225mm |
478*230*225mm |
|
Color |
Space silver/grey+black (multiple colors can be customized) |
||
|
Home Appliance |
BDX-600 |
BDX- 1000 |
BDX- 1200 |
|
Mobile phone charging 5V |
about 48 times or more |
about 90 times or more |
about 90 times or more |
|
LED light 12V |
3W about 150 hours |
3W about 300 hours |
3W about 300 hours |
|
Desktop computer |
about 8 hours |
about 16 hours |
about 16 hours |
|
Fish tank |
about 12 hours |
about 24 hours |
about 24 hours |
|
Laptop |
about 11~ 12 hours |
about 22~24 hours |
about 22~24 hours |
|
Fan 50W |
about 9 hours |
about 16 hours |
about 16 hours |
|
LCD TV(32 inch) |
about 8 hours |
about 16 hours |
about 16 hours |
|
20W energy saving lamp |
about 23 hours |
about 46 hours |
about 46 hours |
|
Inverter refrigerator |
about 12 hours |
about 24 hours |
about 24 hours |
|
Rice cooking 500W |
about 1~2 times |
about 2~4 times |
about 2~4 times |
|
It will automatically switches to grid supply if battery power outage |
|||
Features
ØMini outlook & powerful design, ideal for expedition/camping use.
ØMultiple outputs, charged for 10 devices at the same time.
Ø AC output 600Wh (max)
Ø Type-C * 1 & QC 3.0 * 1, quick charge your phone * laptop.
Ø With multiple circuit protection: short-circuit, over-charge, over-discharge,
Ø Over-current, over-voltage, over-heat,over-load protection function
Ø Small size, light weight, easy to bring and big capacity stored
Ø Compatible with most digital devices in the markets
Ø With LCD screen to know the real-time power
Application
Use for different devices, such as mobile phones, digital products, notebooks, computers, small printers, various lamps, small fish tank heaters, photographic equipment, electric balance wheels, medical device, refrigerators, rice cookers, household appliances, etc.
| Interface No. | Function | Quantity |
| A. | LCD (55mm*25mm) | 1 |
| B. | AC - 220V / 110V output | 4 |
| C. | LED light switch | 1 |
| C1. | LED light power (white light) - 3W | 1 |
| D. | DC switch | 1 |
| E. | AC switch | 1 |
| F. | Built-in Cooling Fans | 2 |
| G. | DC - 12V4A output | 3 |
| H. | USB - 1A output / 2A output | 1 / 1 |
| I. | Computer Communication Connector | 1 |
| J. | USB - PD 3.0 / Type C - PD3.0 | |
| K. | Solar charger indicator light | 1 |
| L. | Input Fuse | |
| M. | Solar energy input (13-18V current ≤7A) | 1 |
| N. | Jump start 12V 20A | 1 |
| O. | AC 110V~220V 50/60Hz | 1 |
Apple devices charging is available
Application
Outdoor activity ,emergency ,medical ,power supply for underdeveloped points of power grid
