UKCA Certificate British Plug 12V 1.5A Switching Mode Power Adapter For Water Flosser

UKCA Certificate British Plug 12V 1.5A Switching Mode Power Adapter For Water Flosser
UKCA Certificate British Plug 12V 1.5A Switching Mode Power Adapter For Water Flosser

Large Image :  UKCA Certificate British Plug 12V 1.5A Switching Mode Power Adapter For Water Flosser

Product Details:
Place of Origin: China
Brand Name: Analog
Certification: UKCA/CE/EN61558
Model Number: GQ18-120150-AB
Payment & Shipping Terms:
Minimum Order Quantity: 1000
Price: Negotiation
Packaging Details: Carton
Delivery Time: 10-25 work days
Payment Terms: T/T,
Supply Ability: 1,600,000~1,800,000PCS/Month

UKCA Certificate British Plug 12V 1.5A Switching Mode Power Adapter For Water Flosser

Description
Output Power: 18 W Output Voltage: 12V
Output Current: 1.5A Input Voltage: 100~240V
Input Frequency: 50/60HZ Input Current: 0.5A
High Light:

1.5A UKCA Switching Mode Power Adapter

,

12V 1.5A Switching Mode Power Adapter

,

UKCA 12v 1.5 a power adapter

UKCA Certificate British Plug 12V 1.5A Switching Mode Power Adapter For Water Flosser



Description




GQ18 products are our 18W series switching power adapter products,  Plug and pins are both fixed and replaceable.

They have excellent performance in temperature rise and EMI. They meet the US Class VI energy efficiency and

the EU CoC Phase 2 energy efficiency requirements.



They have high-precision output OVP, OCP, SCP and other reliable protection functions.

Effectively protect the power supply safety of terminal equipment and the safety of users.





Safety Certificate & EMC



GQ18 Series LVD Certificate.pdf



GQ18 Series CE Certificate.pdf



Product Model Identification



GQ/BZ-  12 xxx yyy ww z
Company code
Output power rating series code
Output voltage code
Output current code
Plug Type
Appliance
For example: Product model No.GQ18-120150-AB stands for Analog brand swithing adapter with 18W series power,12V output voltage,1.5A Output current, plug type is UK  front style AC Plug



Item Specification Datasheet Table Note
Description Product name single-output switch power adapter
Product type Wall mount/Desktop/Interchange Custom Design Available
Model GQ18-120150-AB
Supply Ability 1,600,000~1,800,000PCS/month
Application as per customer requirments,etc Custom Design Available
Mechanical Performance Color Black or White Custom Design Available
Dimensions Subjected to final design Custom Design Available
Output DC Connector 5.5x2.1x10mm optional Custom Design Available
DC Cord / DC Jack L=1.2m / 1.5m or Customized Custom Design Available
Plug type EU ,UK, US, AU, KC, PSE... Custom Design Available
Electrical Performance Output Voltage   12V
Output Current 1.5A
Output Power 18W
Output Ripple Voltage Please refer to the specification datasheet for approval Custom Design Available
Input Voltage & Frequency 90VAC~264VAC, 47~63HZ
Maximum AC Current Please refer to the specification datasheet for approval
Input Inrush Current 40A(RMS) Max, full load tested @AC230V 50HZ
Efficiency VI Custom Design Available
Protection OVP,OCP,OTP,SCP & Input Protection
Environmental requirements Operating Temperature 0~40 ,
Storage Temperature -40~70
Operating Humidity 5%~90% Non-condensing
Storage Humidity 5%~90% Non-condensing
Reliability Warranty 2 year (about 2.28 years for 24-hour-operation a day) Custom Design Available
MTBF 20,000 hour
Insulation Resistanc 30MΩ@500VDC; 60S Custom Design Available
Hi-Pot Meet different safety standard
Leakage Current 0.25mA Max, full load tested @AC230V 50HZ
Compliance with EU directives law & regulations RoHS,REACH,PAHS
Safety Standard Certificate UL/ETL/FCC/CE/ GS/UKCA/ PSE/ KC/ SAA/ EAC/BIS/ICBR Custom Design Available
Standards IEC61558/IEC60335/IEC61347/ETL1310/ IEC62368,GB4943, GB4706,etc... Custom Design Available
EMC EN55014-1/EN55014-2 compliance
ESD (Air discharge@ 8KV, Contact discharge@ 6KV,(IEC61000-4-2) Custom Design Available
Surge ±1KV @ common or different mode Custom Design Available






Optional Plug:UL /GS/BS/SAA/CCC/PSE/EAC

UKCA Certificate British Plug 12V 1.5A Switching Mode Power Adapter For Water Flosser 0





Plug Type Identification
Series No. Plug Type Style Code Description
A_ Front style plug AU US front style AC Plug
AA Austrialian front style AC Plug
AG European front style AC Plug
AJ Japanese front style AC Plug
AK Korean front style AC Plug
AB British front style AC Plug
AR Russian front style AC Plug
AX Interchangeable front style AC Plug
AC Chinese front style AC Plug
ABS Singaporean plug(changeable)
AA1 Argentina front style AC Plug
AUM Mexico front style AC plug
H_or C_ Side style plug HU/CU US side style AC Plug
HA/CA Austrialian side style AC Plug
HG/CG European side style AC Plug
HJ/CJ Japanese side style AC Plug
HK/CK Korean side style AC Plug
HB/CB British side style AC Plug
HR/CR Russian side style AC Plug
HX/CX Interchangeable side style AC Plug
HC/CC Chinese side style AC Plug
Z_ Inline style plug ZU US inline style AC Plug
ZA Austrialian inline style AC Plug
ZG European inline style AC Plug
ZJ Japanese inline style AC Plug
ZK Korean inline style AC Plug
ZB British inline style AC Plug
ZR Russian inline style AC Plug
ZX Interchangeable inline style AC Plug
ZC Chinese inline style AC Plug
E _ Applicance type E1 Input with type C14/C6 used
E2 Desk-top input with type C8 used
E3 Fixed power cord ungrounded
E4 Fixed power cord grounded


UKCA Certificate British Plug 12V 1.5A Switching Mode Power Adapter For Water Flosser 1

Safty Standards

CB -------------IEC 61558/60065/60950/60335-1 / 6134 7-1/61347-2-13
U L--------------ETL 131 0/60065/60950/
GS--------------EN 61558-1 /61558-2-16/60335-1/60950/60065/61347-1/61347-2-13
SAA------------AS/N ZS 61558-2-16/60065 ,/60950
PSE-----------J61558;J55014
CCC----------GB4943.1-2011,GB17625.1-2012,GB9254-2008
CE/EMC------------EN55032/55024/55020/55014-1/55014-2/55015/6154 7
FCC------------Part15B
C-Tick------------CISPR14,CISPR22,CISPR13
EAC------------IEC 61347-1/6134 7-2-13
