Product Details:
|
| Certificate: | UL/CUL/FCC | Efficiency: | VI |
|---|---|---|---|
| Warranty: | 2 Year (about 2.28 Years For 24-hour-operation A Day) | Output: | 24W,24VDC1.0A |
| Protection: | OVP,OCP,OTP,SCP & Input Protection | EU Directive: | RoHS, REACH,PAHS |
| MOQ: | 1K | ||
| Highlight: | CUL Wall Mount Power Adapters,Humidifier Wall Mount Power Adapters,24v 1a Power Adapter |
||
ODM Design EU Plug 24V 1.0 A Power Adapter For Humidifier
Application:Humidifier and other home appliance or smart devices
Specification Datasheet Table
| 24 | |||
| 24V | |||
| Output Current | 1.0A | ||
| Output Power | 24.0W | ||
| Ripple/Noise |
240mVp-p Max.
|
Custom Design Available | |
| Input Voltage & Frequency | 90VAC~264VAC, 47~63HZ | ||
| Maximum AC Current | Please refer to the specification datasheet for approval | ||
| Input Inrush Current | 40A(RMS) Max, full load tested @AC230V 50HZ | ||
| Efficiency | VI | Custom Design Available | |
| Protection | OVP,OCP,OTP,SCP & Input Protection | ||
| Environmental requirements | Operating Temperature | 0~40 ℃, | |
| Storage Temperature | -40~70 ℃ | ||
| Operating Humidity | 5%~90% Non-condensing | ||
| Storage Humidity | 5%~90% Non-condensing | ||
| Reliability | Warranty | 2 year (about 2.28 years for 24-hour-operation a day) | Custom Design Available |
| MTBF | ＞20,000 hour | ||
| Insulation Resistanc | ＞ 30MΩ@500VDC; 60S | Custom Design Available | |
| Hi-Pot | Meet different safety standard | ||
| Leakage Current | 0.25mA Max, full load tested @AC230V 50HZ | ||
| Compliance with EU directives law & regulations | RoHS,REACH,PAHS | ||
| Safety Standard | Certificate | UL/ETL/FCC/CE/ GS/UKCA/ PSE/ KC/ SAA/ EAC/BIS/ICBR/CCC | Custom Design Available |
| Standards | IEC61558/IEC60335/IEC61347/ETL1310/ IEC62368,GB4943, GB4706,etc... | Custom Design Available | |
| EMC | EN55014-1/EN55014-2 compliance | ||
| ESD | (Air discharge@ 8KV, Contact discharge@ 6KV,(IEC61000-4-2) | Custom Design Available | |
| Surge | ±1KV @ common or different mode | Custom Design Available | |
